Ruijie Reyee RG-AirMetro460F, CPE of RG-AirMetro Series Wireless Bridges
Wireless bridge CPE, 5GHz 867Mbps, supports 11ac protocol, IP65, gain up to 23dBi, 1*10/100M port, the base station can be paired with up to 32 CPEs
$55.00
High-Gain Outdoor Wireless Bridge Specifications Table
| Specification | Details |
| Model Reference | RG-AirMetro460G / RG-AirMetro460F series |
| Radio Design | Dual-radio, 3 spatial streams |
| Spatial Stream Config |
Radio 1 (2.4 GHz): 1 x 1, SISO (1 spatial stream) Radio 2 (5 GHz): 2 x 2, MIMO (2 spatial streams) |
| Channel Width Support |
2.4 GHz: Auto / 20 / 40 MHz 5 GHz: Auto / 20 / 40 / 80 MHz |
| Antenna Alignment | Directional dish design |
| Horizontal Beamwidth | 9° |
| Vertical Beamwidth | 9° |
| Product Dimensions (W x D x H) | 368.5 mm x 271 mm x 368.5 mm (14.51″ x 10.67″ x 14.51″) (Installed with bracket) |
| PoE Interface | 1 x PoE In port |
| Operating Temperature | –40°C to +70°C (–40°F to +158°F) |
| Operating Humidity | 5% RH to 95% RH (non-condensing) |
| IP Rating | IP65 (Weatherproof dust and water protection) |
| MTBF | 400,000 hours (~45 years) |
| Bridge Diagnostics | Built-in link bridge speed test supported |
| Network Features | Self-Organizing Network (SON) & AI Heatmap tracking |
| App Management | Remote rebooting/management via Ruijie Reyee App |
| SNMP Management | SNMPv1, v2c, and v3 not supported |
