RG-RAP2260(H) Reyee Wi-Fi 6 AX6000 High-density Multi-G Ceiling Access Point
AX6000 Wi-Fi 6 dual-band Gigabit ceiling mount Indoor AP, 2× 2.5 Gigabit LAN uplink ports, built-in antennas, dual-band 2.4GHz/5GHz, 802.11ax, up to 5952 Mbps access rate per AP; support AP and routing mode, Layer 3 roaming, Reyee unified networking and Ruijie Cloud app management; Local power supply, DC 48V/1A (Note: The power adapter is sold as an optional accessory), 802.3bt PoE.Max power consumption ＜40W. The power supply output should higher than AP max power consumption. Support 802.3bt PoE in and 48V DC power supply. (Reyee 802.3bt PoE injector model: RG-POE-50-60W-MG is sold separately)(Reyee 802.3bt PoE injector model: RG-POE-50-60W-MG is sold separately)
$198.95
Ruijie Reyee RG-RAP2260(H) Access Point Specifications
Hardware & Radio Specifications
| Feature | Specification Details |
| Product Type | High-density Ceiling-mount Access Point (AP) |
| Wi-Fi Standard | Wi-Fi 6 (IEEE 802.11ax) |
| Radio Design | Dual-radio, 8 spatial streams |
| Spatial Streams |
2.4 GHz: 4 x 4, MU-MIMO 5 GHz: 4 x 4, MU-MIMO |
| Max. Wireless Data Rate | Combined: 5950 Mbps |
| 5 GHz Wireless Speed | 4803 Mbps |
| 2.4 GHz Wireless Speed | 1147 Mbps |
| 6 GHz Support | No |
| Antennas | 8 x Built-in omnidirectional antennas (4 x 2.4 GHz, 4 x 5 GHz) |
Physical & Interface Port Specifications
| Feature | Specification Details |
| Multi-G Ethernet Ports | 2 x 10/100/1000/2500BASE-T RJ45 Ports (Dual 2.5G WAN/LAN Uplinks) |
| Dimensions (WxDxH) | 230 mm x 230 mm x 49.5 mm (9.06 in. x 9.06 in. x 1.95 in.) (excludes mounting bracket) |
| Weight | $\le$ 1.36 kg (3.00 lbs) (without packaging) |
| Color | White |
| Mounting Options | Ceiling-mount or Wall-mount |
Power, Environment & Reliability
| Feature | Specification Details |
| Power Supply Options |
Local DC power adapter or PoE+ / PoE++ (IEEE 802.3at/bt) (Note: If both DC and PoE are connected, DC power is preferred) |
| Local Power Rating | 48 V / 1 A |
| DC Connector Dimensions | Outer Diameter: 5.5 mm | Inner Diameter: 2.1 mm | Depth: 10 mm |
| PoE Passthrough (Budget) | No |
| Max. Power Consumption | 40 W |
| IP Rating | No |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Warranty | 1 Year |
Software Specifications
| Feature | Specification Details |
| Max. Associated Clients |
2.4 GHz: 64 clients 5 GHz: 512 clients Combined Band Limit: 512 clients |
| Max. Managed Devices | Up to 300 network devices |
| IPv6 Support | Yes |
| Network Features | Support for Ruijie Cloud remote monitoring, Reyee Mesh wireless expansion, custom captive portal authentication, and Self-Organizing Networks (SON) |
