Name: RG-RAP2200(F) Reyee Wi-Fi 5 1267Mbps Ceiling Access Point
SKU: RG-RAP2260
Price: 64.01 USD
Availability: InStock

Ruijie Reyee RG-RAP2200(F) Ceiling Access Point Specifications

Feature	Specification Details
Product Type	Ceiling-mount Access Point (AP)
Wi-Fi Standard	Wi-Fi 5 (802.11ac Wave 2) with MU-MIMO support
Radio Design	Dual-radio, 4 spatial streams
Spatial Streams	2.4 GHz: 2 x 2 MIMO 5 GHz: 2 x 2 MIMO
Max. Wireless Speed	Combined: 1266 Mbps
5 GHz Wireless Speed	866 Mbps
2.4 GHz Wireless Speed	400 Mbps
6 GHz Support	No
Antennas	4 x Built-in omnidirectional antennas (2 x 2.4 GHz, 2 x 5 GHz)
Antenna Gain	2.0 dBi (both bands)

Feature	Specification Details
Network Ports	2 x 10/100BASE-T RJ45 Fast Ethernet ports
Dimensions (WxDxH)	194 mm x 194 mm x 35 mm (7.64 in. x 7.64 in. x 1.38 in.) (excludes mounting bracket)
Weight	$\le$ 0.45 kg (0.99 lbs) (without packaging)
Color	White
Mounting Options	Ceiling-mount or Wall-mount

Feature	Specification Details
Power Supply Options	12 V DC local power adapter or PoE/PoE+ (IEEE 802.3af/at) (Note: If both options are connected, the local DC input is preferred)
DC Connector Dimensions	Outer Diameter: 5.5 mm \| Inner Diameter: 2.1 mm \| Depth: 10 mm
Local Power Rating	12 V / 1.5 A
PoE Passthrough (Budget)	No
Max. Power Consumption	12.95 W
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	–40°C to +70°C (–40°F to +158°F)
Operating Humidity	5% to 95% RH (non-condensing)
IP Rating	No
Warranty	1 Year

Feature	Specification Details
Max. Wireless Clients	2.4 GHz: 64 clients 5 GHz: 110 clients Combined Band Limit: 110 clients
Max. Managed Devices	Up to 150 network devices
IPv6 Support	No
Network Management	Support for Ruijie Cloud remote monitoring, Ruijie Reyee App configuration, and Self-Organizing Networks (SON)

SKU: RG-RAP2260 Categories: Ceiling AP, Ruijie Reyees Products, SMB

Barcode:

RG-RAP2200(F) Reyee Wi-Fi 5 1267Mbps Ceiling Access Point
